AEG AC1030S - Page 3

3
3
1
2
4
1
2
3
3
1
Fig. 2
Fig. 1
Fig. 4
Fig. 5
Fig. 3
11
10
13
7
8
9
12
14
4
5
6
1
2
3
1 - Wheel
2 - M10 step bolt
3 - M10 washer (1.5mm)
4 - M10 spring washer
5 - M10 hex nut
6 - Wheel axle cover
4
3
5
1
2
6
1 - Air filter assembly
1 - Front handle
2 - Handle slot
3 - Bolt
1 - Rubber foot
2 - M8 flat washer
3 - M8 bolt
4 - M8 hex nut
1 - Air filter assembly x2
2 - Pressure relief valve
3 - Power cord
4 - Front handle
5 - AUTO/OFF switch
6 - Pressure regulator knob
7 - Regulator pressure gauge
8 - Tank pressure gauge
9 - Quick connect coupler
10 - Tank
11 - Rubber foot x2
12 - Wheel x2
13 - Rear handle
14 - Drain valve
