Fig. 7
Fig. 8
Fig. 6a Fig. 6b
Fig. 9
1
1 - Quick connect coupler
2 - Quick connect air fitting
3 - To close (counterclockwise)
4 - Pressure relief valve
5 - Regulator locking ring
1 - Quick connect air fitting
2 - Quick coupler
1 - AUTO position
2 - OFF position
3 - Tank pressuse gauge
4 - Regulated pressure gauge
5 - To open (clockwise)
6 - Regulator locking ring
