No. Description No. Description No. Description No. Description
1 Pump assembly 1-31 Spring 13-5 Bolt 15 Elbow exhaust
1-1 Crankcase 1-32 Washer 13-6 Obturating ring 16 Exhaust
1-2 Oil plug 1-33 Nut 13-7 Cover 17 Elbow exhaust
1-3 Shaft seal 1-34 Crank shaft 13-8 Capacitance box 18 Unloading pipe
1-4 Oil glass 1-35 Bearing 13-9 Key 19 Elbow
1-5 Oil plug 1-36 Oil sealing 13-10 Belt pulley 20 Check valve
1-6 Gasket 1-37 Gasket 13-11 Bolt 21 Exhaust pipe
1-7 Cylinder 1-38 Bearing cover 13-12 Spring 22 U style handle assembly
1-8 Spring 1-39 Breather 13-13 Bearing crank 22-1 Handle cover
1-9 Bolt 1-40 Flywheel 13-14 Bolt 22-2 Handle
1-10 Gasket 1-41 Washer 13-15 Pedestal 23 Bolt
1-11 Valve 1-42 Spring 13-16 Stator 24 Block up
1-12 Valve plate 1-43 Bolt 13-17 Rotator 25 Nut
1-13 Gasket 1-44 Bolt 13-18 Bearing 26 Bolt
1-14 Gasket 1-45 Spring 13-19 Bearing crank 27 Washer
1-15 Cylinder head 2 Nut 13-20 Fan 28 Cushion foot
1-16 Metal filter 3 Washer 13-21 Cover 29 Washer
1-17 Bolt 4 Washer 13-22 Bolt 30 Nut
1-18 Head cover 5 Bolt 13-23 Washer 31 Drain cock
1-19 Bolt 6 Bolt 13-24 Bolt 32 Nut
1-20 Spring 7 Washer 13-25 Spring 33 Washer
1-21 Piston ring 8 Washer 13-26 Washer 34 Nut
1-22 Piston ring 9 Cover 13-27 Nut 35 Wheel
1-23 Piston 10 V belt 14 Regulator assembly 36 Bolt
1-24 Piston pin 11 Plug 14-1 Pressure switch 37 Tank
1-25 Circlip 12 Electrical wire 14-2 Pressure gauge
1-26 Connecting rod 13 Motor 14-3 Safety valve
1-27 Spindle 13-1 Circuit breaker 14-4 Nog
1-28 Bolt 13-2 Safety carriage 14-5 Quick valve
1-29 Bearing 13-3 Capacitance 14-6 Lock nut
1-30 Bolt 13-4 Capacitance 14-7 Regulating cap
