AEG BEB231011M - Control Panel; Buttons; Display

5. PRODUCT DESCRIPTION
5.1 General overview
8
7
11
9
10
5
4
1
2
3
33 641 52
1
Control panel
2
Knob for the heating functions
3
Power lamp / symbol
4
Display
5
Control knob (for the temperature)
6
Temperature indicator / symbol
7
Heating element
8
Lamp
9
Fan
10
Shelf support, removable
11
Shelf positions
5.2 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Grill- / Roasting pan
To bake and roast or as pan to collect
fat.
• Trivet
For roasting and grilling.
Use the trivet only with
the Grill- / roasting pan.
6. CONTROL PANEL
6.1 Buttons
Sensor field / Button Function Description
MINUS To set the time.
CLOCK To set a clock function.
PLUS To set the time.
6.2 Display
A B C
A. Clock functions
B. Timer
C. Clock function
