11.10 How to replace: Lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
Before you replace the lamp:
Step 1 Step 2 Step 3
Turn off the oven. Wait until
the oven is cold.
Disconnect the oven from
the mains.
Put a cloth on the bottom of
the cavity.
Top lamp
Step 1 Turn the glass cover to remove
it.
Step 2 Remove the metal ring and clean the glass cover.
Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp.
Step 4 Attach the metal ring to the glass cover and install it.
Side lamp
Step 1 Remove the left shelf support
to get access to the lamp.
Step 2 Use a Torx 20 screwdriver to
remove the cover.
Step 3 Remove and clean the metal
frame and the seal.
Step 4 Replace the lamp with a suita‐
ble 300 °C heat-resistant
lamp.
Step 5 Install the metal frame and the
seal. Tighten the screws.
Step 6 Install the left shelf support.
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
