Page #10 background image
5. HOB - DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Heat setting
Symbols Function
Off position
Double zone
1 - 9 Heat settings
Use the residual heat to
decrease energy
consumption. Deactivate the
cooking zone approximately
5 - 10 minutes before the
cooking process is
completed.
Turn the knob for the selected cooking
zone to a necessary heat setting.
To complete the cooking process, turn
the knob to the off position.
5.2 Activating and
deactivating the outer rings
You can adjust the surface you cook to
the dimension of the cookware.
To activate the outer ring: turn the
knob clockwise through a light resistance
to
. Then turn the knob
counterclockwise to the correct heat
setting.
To deactivate the outer ring: turn the
knob to the off position. The indicator
goes out.
5.3 Residual heat indicator
WARNING!
There is a risk of burns from
residual heat.
The indicator comes on when a cooking
zone is hot, but it does not function if
mains power is disconnected.
6. HOB - HINTS AND TIPS
WARNING!
Refer to Safety chapters.
6.1 Cookware
The bottom of the cookware
must be as thick and flat as
possible.
Ensure pan bases are clean
and dry before placing on
the hob surface.
Cookware made of
enamelled steel and with
aluminium or copper
bottoms can cause a colour
change on the glass-ceramic
surface.
6.2 Examples of cooking
applications
The data in the table is for
guidance only.
Heat setting Use to: Time
(min)
Hints
1 Keep cooked food warm. as nec-
essary
Put a lid on the cookware.
1 - 2 Hollandaise sauce, melt: but-
ter, chocolate, gelatine.
5 - 25 Mix from time to time.
www.aeg.com10
Question and Answer IconNeed help?

Do you have a question about the AEG CCS6741ACM and is the answer not in the manual?

AEG CCS6741ACM Specifications

General IconGeneral
Oven Capacity73 L
Energy Efficiency ClassA
Number of Functions9
Control TypeRotary
ColorStainless Steel
Hob typeCeramic
Number of Burners4
Width60 cm
Voltage230 V
Frequency50 Hz
Dimensions (H x W x D)600 x 600 x 600 mm
