AEG COMPETENCE D4100-1 - Accessing the Mains Terminal

TO REMOVE COVER OF MAINS TERMINAL
From the rear of the appliance, remove mains input
terminal cover to gain access to terminal block.
First remove retaining screw with pozidrive
screwdriver. See Fig. 4.
Prise cover loose using screwdriver in position (1)
then lever off with screwdriver in position (2) at either
side. See Fig. 5.
Lift cover and remove screw from cable clamp. See
Fig. 6.
44
Fig.4
Fig.5
Fig.6
