61
Water drain
The drainage hose can either be connected to a siphon or hung in a
wash basin or discharge basin or a bath tub.
Only original hoses may be used for extensions (max. 3m laid on the
floor and then up to 80cm high). Customer Service stocks drainage
hoses in lengths of 2.7 and 4m.
Important! It is essential to lay the drainage hose without kinks.
Water drain-off inside a siphon
The grommet on the hose end fits
all standard siphon types.
Secure the connection between
the grommet and siphon with a
hose clamp.
Water drain-off inside a basin
Important!
– Small basins are not suitable for
drainage. Water could overflow!
– The end of the drainage hose
must not be submerged in the
pumped-out water. Otherwise,
the water could be sucked back
into the unit.
– When hanging in a wash basin
or a bath tub, the drainage hose
must be secured with the sup-
plied attachable bend to pre-
vent it slipping. The back-surge
force of the escaping water
could otherwise force the hose
out of the basin.
Tie the bend to the tap or the wall
using a piece of string.
Delivery heads over 1m
To pump off the washing / rinsing solution, every washing machine has
a drain pump which carries liquids up to a height of 1m via the drain-
age hose, calculated from the machine's standing surface.
Please contact Customer Service for delivery heads of over 1m.
