The controller contains an externally accessible fuse; no additional fuses are required. Use the supplied zip-ties
to mount the controller.
Progressive Controller Installation
Connect to ground (black) wire of pump.
Connect to ground (black) wire of external LED.
Connect to positive (red) wire of external LED.
1.5A Low Side output. Connect to optional flow control
solenoid.
1.7A Low Side output, grounded when error condition
exists.
Connect to the positive (red) wire of pump.
Main ground connection. Connect directly to battery
ground.
Connect to the white wire of the fluid tank level
sensor*
Connect to the black wire of the fluid tank level
sensor*
Arms injection system. Connect to a switched 12V
source.
Main Power Connection. Connect directly to positive
battery terminal.
*Note: If fluid tank is equipped with previous generation level sensor, identified by having two black wires, then pins 8 (white)
and 9 (brown) may be connected to either of the two black sensor wires. The polarity is unimportant.
**Note: If you need to extend the wires to mount the controller use at least 16 AWG wire for the pump and controller ground
circuits and 18 AWG for the remainder.
External LED Install
Find a suitable location in the driver’s line of sight to mount the external LED. Mount the LED and run the wires
to the controller. The LED indicates the operation of the controller. If the pump is off and there are no errors, the
LED will be off. If there are no errors and the pump is on, the LED intensity will vary with the pump speed. If
there are any errors, they will be indicated by flashing the LED.
Boost Pressure Hose
Using the supplied vacuum tee and rubber hose, tap into a manifold pressure (vacuum/boost) line.
