Progressive Limit Gauge
The Progressive Limit gauge is typically used to signal an approaching rev limit by means of several boxes that
change color as the rev limit approaches. This gauge has the following special properties:
· Box Count is the number of boxes in the gauge.
· Box Size is the width and height of the box in pixels.
· Limiter Start is the value at which the first box will change color from Background color to Fill color.
· Limiter Offset is the value added to the Limiter Start to determine when the next box changes color.
· Draw Circular Limit Lights - if checked, round LED style boxes will be drawn instead of boxes.
For example, if Box Count is 3, Limiter Start is 8000 and Limiter Offset is 200, the first box will change
color at 8000, the second at 8200 and the third at 8400.
