The AENO RC1S Robot Vacuum cleaner is a household device designed
for an automatic cleaning of premises.
Specifications
Robot
Dimensions: Ø330mm × 330mm × 98mm. Net weight: 3.3kg. Vacuum cleaner
supply voltage: 19VDC (Input), 1A, 60W. Capacity of rechargeable li-ion built-in
battery: 5,200mAh. Power adapter voltage: 100-240VAC; Frequency: 50/60Hz.
Dust bin capacity: 600ml. Water tank capacity: 370ml. Operating time: 62-
215min. Operating temperature: 0 °C to +40 °C. Charging time: 300-360min.
The maximum height of bridged obstacles: 18mm. Controls: Manual, remote,
and/or via the AENO mobile application.
Docking Station
Dimensions: 230 mm × 225 mm × 345 mm. Net Weight: 3.2 kg. Input: 220-
230VAC, 5A. Output: 19VDC, 1A. Rated Power: 1050W. Working Noise: about 80
dB. Suction Time: 15 sec. Dust Bag Capacity: 2.8 l. Number of cleanings before
the dust bag fills up: 40.
Package Contents (See Figure a)
Robot vacuum cleaner – ❶, docking station – ❷, remote control – ❸, power
adapter – ❹, cleaning brush – ❺, dust container – ❻, side brushes (4 pc.) – ❼,
HEPA filter – ❽, foam filter – ❾, mop for cleaning – ❿, water tank – ⓫, batteries
for the remote control – ⓬, quick start guide, warranty card, dust bag (5 pc.)
Limitations and Warnings
ATTENTION! Two UV disinfection lamps are installed at the bottom of the
vacuum cleaner, between the roller brush and the battery cover (See Figure i).
Ultraviolet radiation is very dangerous and may damage eyes, if you look at the
lamps while operation. Never turn the vacuum cleaner upside down while it is
on.
Do not disassemble or repair the device on your own. Do not use the device in
areas with an ignition or explosion risk, or near open flames. Use the original
