X. RESET NANOMOTE QUAD
Reset procedure clears the NanoMote Quad's memory, including Z-Wave network information.
To reset NanoMote Quad:
Press and hold the button for 20 seconds, the LED light will be solid on in red. Then release the
button, the LED light will be stay in red for 2 seconds, during this 2 seconds, please click the button
once, it will start to restore factory default. At the same time, the LED light will be solid on in
colorful for 15 seconds. Then Sending Device Reset locally notification to the controller.
NOTE:
Use this procedure only in the event that the network primary controller is
missing or otherwise inoperable.
XI. BATTERY CHARGING
NanoMote Quad has an internal rechargeable battery that will run for three months under the
normal use condition. The charger's output should be a micro USB terminal with the specification
of output DC 5V.The LED color is red during the charging process, and it will turn to green if the
charging is finished.
Ⅻ. BASIC COMMAND
There is no relevant commands are available for mapping.
ⅩⅢ. BATTERY COMMAND
NanoMote Quad will send battery report to the lifeline group when Button is triggered during the
sleep mode. If the battery level of the Scene Controller is less than 20%, the Scene Controller will
beep 3 times when the button is pressed.
ⅩⅣ. ASSOCIATION
Association allows the NanoMote Quad to control another Z-wave device directly, such as Smart
Switch, Smart Dimmer, etc. NanoMote Quad supports three association groupings, every group
relates to a specific button action. View details in the follow section of “XI. BUTTON FUNCTION”.
Group 1 allows NanoMote Quad sends central scene notification command and battery report
command when any button is triggered. Details shown as the below diagram 1.
