phones Output for a stereo headphone set.
6.3 mm stereo jack socket.
Never use mono jack plugs,
otherwise the amp could be damaged!
tuner Output to an external tuner. 6.3 mm mono jack socket.
line out preamplier output after the master control.
6.3 mm mono jack socket.
DI-out Balanced preamp output, pre master, post EQ,
with return and eects. XLR socket
send Output to the input of an external eects unit.
6.3 mm mono jack socket.
return Input for the output signals of an external eects
processor. 6.3 mm mono jack socket.
footswitch connection to a double footswitch to switch internal
and external eect on and o.
(Tip = internal Eect, Ring = external Eect on/o).
6.3 mm stereo jack socket.
power on Combined power switch with fuse holder and IEC
mains socket
Back panel (from left to right):
Caution: Risk of electric shock. Do not open! No user serviceable parts inside.
Refer servicing to qualied personnel. Made in Germany by AER.
Compact 602
twin channel acoustic amplifier
