AER COMPACT 60 2 - Technical Data

6
5. Technical Data
Inputs
Input (channel 1) Stereo jack ¼” (6.35 mm)
High impedance, unbalanced jack input for
instruments (pick-ups) and line-level sources.
high/low switch: –10 dB attenuator
Impedance: 2.2 Meg
Input (channel 2) Combo socket, XLR jack ¼” (6.35 mm)
line mode:
High impedance, unbalanced jack input for
instruments (pick-ups) and line-level sources.
Sensitivity: 38 mV
Impedance: 1 Meg
mic mode:
XLR (balanced), stereo jack (balanced),
or mono jack (unbalanced) input.
Voice Filter
24 V-Phantom-Power through 6.8 kohms
to XLR socket
Clip indicator: Headroom 6 dB
Return Return from external parallel eect loop
Sensitivity: 430 mV
Clip Headroom: 15 dB
Attack Time: 4 ms
Outputs (note 3)
Phones Headphones output. When connected, internal
speakers are muted.
Stereo jack, ¼” (6.35 mm)
Output power: 100 mW
Caution: For stereo headphones with stereo jack
plug only. Do not connect mono plugs.
Tuner Tuner output. Mono jack, ¼” (6.35 mm)
Output voltage: 310 mV
Line out Line output after tone controls,
with return and eects.
Mono jack, ¼” (6.35 mm).
Output Voltage: 1.3 V
DI-out Line output after tone controls,
with return and eects.
Mono jack, ¼” (6.35 mm).
Output Voltage: 1.3 V
Send Send for parallel eect loop
Mono jack, ¼” (6.35 mm)
Output voltage: 1.3 V
Tone controls
Bass channel 1: ± 8 dB at 100 Hz
channel 2: ± 8 dB at 100 Hz
Middle channel 1: ± 6 dB at 800 Hz
Treble channel 1: ± 8 dB at 10 kHz
channel 2: ± 11 dB at 10 kHz
Eects
Internal eect digital eect processor with 4 factory presets
1 – warm hall
2 – bright hall
3 – chorus with reverb
4 – anger
External eect Parallel eect loop (see send and return)
Power
Power amp 60 W at 4 ohms,
discrete bipolar transistor design
Analog signal Subsonic lter, low distortion RMS limiter
processing
Speaker system 8” (200 mm) twin cone speaker
Mains power AC 230 V, 50-60 Hz, max. 120 W
(other mains voltage available)
Mains fuse slow 1 A for 230-240 V
slow 2 A for 115 V
slow 2 A for 100 V
General
Cabinet 15 mm (0.6”) nnish birch plywood
Finish Waterbased acrylic, choco spatter nish
Dimensions 265 mm (10.4 “) high
330 mm (13 “) wide
235 mm (9.25 “) deep
Weight 7,55 kg (16.65 lbs)
Notes:
Input levels refer to 50 Watts output.
Output levels refer to 50 mV input at channel 1.
Specications and appearance subject to change without notice.
