APPENDIX E – PARTS LIST DRAWINGS
OMM-0078_0L AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 151 of 206
GF-128 Phone: 800-526-0288 PRI: 11/25/2014
APPENDIX E – PARTS LIST DRAWINGS
Innovation 600/800/1060/1350 Parts List
Item
Qty
Part #
Description
Item
Qty
Part #
Description
HEAT EXCHANGER
1 
1
24336-1
PLATED HEAT EXCHANGER KIT INN600, INN800
31
1
39144
LOWER HEAD RING ASSY
1
24336-3
PLATED HEAT EXCHANGER KIT INN 1060
32
2
34063
LEG: BASE
1
24336-4
PLATED HEAT EXCHANGER KIT INN 1350
33
1
30090
PANEL: ELECTRICAL
DYNAMIC LOAD ANTICIPATOR ASSY
GASKETS / "O" RINGS
2
1
69103
CIRCULATOR PUMP
34
1
GP-18900
SEAL: MANIFOLD TO LOWER HEAD
3
1
59170
SHUT-OFF SWIVEL FLANGE
35
1
GP-122537
GASKET: EXH MANIF TO COMB CHAMB
4
1
92092
T&P VALVE 3/4F X 3/4F
36
2
GP-18899
BURNER GASKET
5
3
123449
SENSOR: TEMPERATURE
37
1
81136
GASKET: INTAKE MANIFOLD
6
1
92091
BALL VALVE, 1”
38
1
81197
SHIELD GASKET
39
1
81048
GASKET: FLAME DETECTOR
GAS TRAIN
40
2
GP-18532
SHELL GASKET: 1/16 THK
7 
1
22122
FM GAS TRAIN INN600/800/1060 1” NAT GAS
41
1
GP-18556
RELEASE GASKET
1
22122-1
DBB GAS TRAIN, INN600/800/1060 NAT GAS
42
1
GP-123077
UPPER HEAD COPPER LINER
1
22168
D FM 1" GAS TRAIN, INN 1350
43 
1
81064
GASKET: BLOWER OUTLET
1
22168-1
DBB GAS TRAIN, NAT GAS, INN 1350
44 
1
81057
GASKET: A/F VALVE OUTLET
1
22179
FM GAS TRAIN, 600/800 ½“ PROPANE
45

1
88003
O-RING #2-339
1
22179-1
DBB GAS TRAIN, 600/800 ½“ PROPANE
46
1
88004
O-RING #2-244 BUNA-N
1
22180
FM GAS TRAIN, 1060 ¾” PROPANE
CONTROLS
1
22180-1
DBB GAS TRAIN, 1060 ¾” PROPANE
47
1
64099
POWER BOX ASSY - with SEQ VALVE
1
22182-1
FM GAS TRAIN INN1350 1” NAT GAS
1
64077
POWER BOX ASSY – w/o SEQ VALVE
1
22182-4
FM GAS TRAIN, 1350 ¾” PROPANE
48
1
65085
TRANSFORMER: IGNITION
EXHAUST MANIFOLD
49 
1
65146
IGNITION CABLE ASSEMBLY
8
1
44085-1
6" EXHAUST MANIFOLD - INNOVATION
9 
1
123449
SENSOR: EXHAUST TEMPERATURE
50 
1
63072
HARNESS: SHELL WIRING
AIR FUEL DELIVERY SYSTEM - BLOWER, A/F VALVE & ACCEESS
51 
1
63079
HARNESS: INNOVATION CONTROL
10 
1
58039
BLOWER REPLACEMENT KIT : AMETEK 8.9"
52
1
69158
I/O BOX WITH ONAER with SEQ VALVE
11 
1
24311-3
A/F VALVE ASSY, INN 600/800/1060
1
69153
I/O BOX WITH ONAER & w/o SEQ VALVE
1
24311-4
A/F VALVE ASSY, INN 1350 ONLY
53
1
65175
THERMOSTAT, JUMO
12
1
59138
AIR FILTER: 6"
13
1
61024
AIR INLET TEMPERATURE SENSOR
55 
1
69126
LOW WATER CUT-OFF (LWCO) KIT
14
1
60011-4
SWITCH ASSY: BLOWER PROOF
56
1
69186-2
C-MORE CONTROL BOX
1
60011-3
SWITCH ASSY: BLOWER PROOF, INN 1359 ONLY
57 
1
161450
HARNESS, GAS TRAIN MAIN WIRING (FM
& DBB)
15
1
61002-5
BLOCKED INLET SWITCH -8.0" W.C.
58 
1
124024
HARNESS, DBB GAS TRAIN
BURNER
16 
1
24335-1
LOW NOx BURNER ASSY KIT
OTHER PARTS
17
1
44086
LOW NOX BURNER MTG PLATE
59
5
59133
LATCH, COMPRESSION
60
32142-1
BAFFLE ASSY HEAT EXCHANGER
ENCLOSURE - BASE ELECTRICAL PANEL
61
1
74018
INN 600 LOGO
18
1
37094
FRONT PANEL ASSY - EYELET
1
74019
INN 800 LOGO
19
1
37098
PANEL: TOP
1
74020
INN 1060 LOGO
20
1
37097
PANEL, LEFT REAR
1
740201
INN 1350 LOGO
21
1
37081
COVER: PIPE 1"
62
1
89037
BAFFLE SEAL (component of item 60)
22
1
37101
REAR PANEL: UPPER RIGHT
63
1
49209
CONDENSATE SHIELD
23
1
37102
ACCESS PANEL: RIGHT REAR
74
1
59039
6" WORM-DRIVE HOSE CLAMP
24
1
37104
RIGHT SIDE ZERO CLEARANCE PANEL
75
1
39125
ADAPTER: AIR INLET 6" PVC
25
1
37103
LOWER PANEL: RIGHT REAR
26
1
37096
FRONT DOOR ASSY
77
1
97005-9
TUBE, FLEXIBLE GAS, 48”
27
1
37099
PANEL, SIDE
78 
1
61034
AC CURRENT TRANSDUCER
28
1
37063
PANEL: REAR
79
1
63118
IGNITER GROUND WIRE ASSY.
29
1
30081
PANEL: BASE COVER
80
1
24060
CONDENSATE TRAP ASSY.
30
1
34061
BASE FORMED 26 X 40
81
1
80088
EXHAUST MANIFOLD SEAL
AERCO International,
Inc. Blauvelt, NY
10913
Innovation Parts List
10/30/2014
Top Level
Page 1 of 4
