Aerco KC Series - Page 96

APPENDIX E
E-6
TABLE 1
BEFORE G-07-0883
G-07-0883 AND AFTER
SERIAL NUMBER
ITEM 15 PART NUMBER
GP-122512
53013
1/4"NPT x 3/8"OD TUBE 90° COMP. FTG.
PUMP OUTLET TUBE
1/4"NPT STREET ELBOW
1/4"NPT CLOSE NIPPLE
1/4"NPT BALL VALVE
CIRCULATING PUMP
2" COLD WATER INLET PIPE
1
GM-18859 1
GP-122756
GP-9-430
92076
GP-8-3-1
GP-122759
2
4
3
6
5
7
1
1
3
12823 2
3
1
2"NPT 90° COLD WATER INLET ELBOW
HYD. ZERO & CONT. ORIFICE TUBE ASS'Y
1/4"NPT x 3/8"OD TUBE STR. COMP. FTG.
1/4"NPT x 3/8"OD TUBE 45° COMP. FTG.
HOT WATER MIXING ORIFICE ASS'Y
COLD WATER MIXING ORIFICE ASS'Y
BTU TRANSMITTER SENSOR
ORIFICE DISC
ORIFICE RETAINING CLIP
TUBING ASS'Y
HYDRAULIC ZERO NEEDLE VALVE
122075
GP-122677-1
GP-122613-1
GM-122687
GM-122761
GP-122506
GM-122400
11
9
8
10
12
14
13
1
1
1
1
1
4
1
123449
GP-122552
GM-161212
SEE TABLE 1
16
15
17
18
1
1
1
1
ITEM DESCRIPTION
KC1000 WATER HEATER
QTY.PART NO.
(SH. 1 OF 2)
PL-A-134
BTU TRANSMITTER ASSEMBLY
KC1000 WATER HEATER
NORTHVALE, NJ 07647
INTERNATIONAL, INC.
SCALE
APPD.
DWN.BY
041304
CZ
DATE
DATE
AERCO
D
(COMPLETE ASS'Y GM-20872)
5
4
18
16
6
2
13
3
7
