Aerco KC Series User Manual

APPENDIX E
E-9
12
6
11
5
9
1
7
10
8
2
4
14
13
DO NOT
CUT WIRES
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 124866 SOLENOID VALVE, 1/4" NPT
2 1 122712 1/2" NPT, FLEX, GAS HOSE, 12" LONG
3 1 123314 ELBOW, 1/4" NPT
4 1 9-43 REDUCER BUSHING, 1/2" TO 1/4" NPT
5 1 124933 UNION, 1/4" NPT
6 1 124934 1/4" X 1/8" REDUCING COUPLING
7 2 124088 NIPPLE, 1/4" NPT, C.S. 2 1/2" LONG
8 1 124932 REDUCING COUPLING, 1/2" TO 1/4" NPT
9 1 124910 NIPPLE, 1/4" NPT, CS. 9" LG
10 1 92076 1/4" NPT BALL VALVE
11 1 124939 1/4" NPT ORIFICE PIPE NIPPLE
12 1 124979 1/8" C.S. STREET ELBOW
13 2 124891 FEMALE FAST-ON CONNECTOR
14 1 12607-2 CLOSE NIPPLE, 1/4" NPT SCH.40, C.S.
LOW NOx STAGED IGNITION ASSEMBLY – 124867
