WS3085
7
|
P a g e
Figure 1
Figure 2
1.
Wind Speed Sensor/Anemometer
7. Antenna
2. Wind Vane
8. U
-
Bolt
3. Thermo
-
hygro
sensor
9. Battery compartment
4. Rain collector
10. Reset button
5. Bubble level
11. LED Indicator: light on for 4s if
the unit power up. The LED
will flash once every 48
seconds.
6. Solar panel
12.UV/Light sensor
