POSITION FOR DRILLING HOLES OF
SERVICE:
Pre-cut side
(right and left sides)
This type of unit draws air laterally and enters the
environment through two turns distinct, one high and
one low; but you can rule out Lower discharge through
the following steps:
1. Open the front panel.
2. Use the selector outlet (located on the left enables
the double-locked, right single upper delivery).
SELECTION OF AIR DELIVERY
Delivery
Suction
ATTENTION:
You should not change the flow manifold as the unit
is specifically designed for optimum performance
using the double-locked.
The unit is set up by default to use the double-
locked.
To Next Page
