AERMEC FCL 42 - Heating Capacity

44
IFCLTY 1112 - 4528511_04
0,5 1 1,5 2 2,5
3
Water flow rate [l/h]
t °C (water inlet temperature - air inlet temperature)
Heating capacity [kW]
FCL 34
Water flow rate [l/h]
t °C (water inlet temperature - air inlet temperature)
Heating capacity [kW]
FCL 36
0,5 1 1,5 2 2,5
3
Water flow rate [l/h]
t °C (water inlet temperature - air inlet temperature)
Heating capacity [kW]
FCL 38
Water flow rate [l/h]
t °C (water inlet temperature - air inlet temperature)
Heating capacity [kW]
FCL 42
0,5 1 1,5 2 2,5 3 3,5
Portata acqua [l/h)
t °C (water inlet temperature - air inlet temperature)
Heating capacity [kW]
FCL 44
HEATING CAPACITY [kW]
Water flow rate [l/h]
t °C (water inlet temperature - air inlet temperature)
Heating capacity [kW]
FCL 32
HEATING CAPACITY CORRECTION FACTORS
Portata acqua (l/h)
t °C (water inlet temperature - air inlet temperature)
Heating capacity [kW]
FCL 62
0 0,5 1 1,5 2 2,5 3 3,5 4 4,5
Portata acqua (l/h]
t °C (temperatura acqua entrante - temperatura aria entrante]
Heating capacity [kW]
FCL 64
The heat yields refer to the maximum speed. For the rest of the speeds the values must be multiplied by the following factors:
FCL 32 34 36 38 42 44 62 64
Speed 4 - - - - 1 1 1 1
Speed 3 1 1 1 1 0,81 0,89 0,80 0,89
Speed 2 0,82 0,84 0,75 0,84 0,61 0,78 0,66 0,81
Speed 1 (minimum)
0,71 0,75 0,60 0,75 0,50 0,72 0,55 0,75
