IFCLTY 1112 - 4528511_04
Tw
[°C]
T [°C]
Ta
W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 1839 1839 2296 2296 2740 2740 3174 3174 3608 3608 3823 3823
17 2509 1940 2599 2442 2795 2795 3182 3182 3616 3616 3831 3831
19 3901 1957 3893 2434 3886 2906 3890 3384 3972 3875 4019 4019
21 5363 2426 5352 2903 5341 3374 5329 3845 5324 4077
23 6927 2879 6910 3354 6899 3830 6887 4064
5
15 1501 1501 2011 2011 2490 2490 2951 2951 3401 3401 3624 3624
17 1728 1563 2095 2095 2494 2494 2955 2955 3409 3409 3632 3632
19 3080 1616 3088 2094 3182 2598 3358 3123 3589 3589 3718 3718
21 4675 2142 4667 2618 4667 3092 4667 3565 4691 3810
23 6285 2617 6285 3097 6262 3565 6262 3803
7
15 879 879 1579 1579 2142 2142 2646 2646 3127 3127 3362 3362
17 881 881 1587 1587 2146 2146 2654 2654 3135 3135 3366 3366
19 1454 964 2009 1626 2427 2231 2814 2814 3194 3194 3389 3389
21 3635 1732 3643 2209 3753 2718 3925 3245 4026 3509
23 5488 2305 5483 2779 5477 3251 5466 3482
13
3
15 1368 1368 1837 1837 2289 2289 2728 2728 3162 3162 3377 3377
17 1477 1452 1841 1841 2295 2295 2732 2732 3170 3170 3385 3385
19 2689 1458 2682 1926 2748 2418 2908 2908 3178 3178 3393 3393
21 4175 1942 4167 2416 4159 2883 4151 3350 4171 3592
23 5739 2402 5733 2878 5716 3345 5710 3579
5
15 930 930 1517 1517 2017 2017 2490 2490 2947 2947 3174 3174
17 934 934 1519 1519 2021 2021 2494 2494 2955 2955 3182 3182
19 1462 970 1833 1557 2189 2129 2545 2545 2959 2959 3186 3186
21 3331 1616 3331 2088 3401 2578 3549 3093 3635 3350
23 5011 2124 4999 2593 4988 3060 4988 3295
7
15 444 444 887 887 1614 1614 2158 2158 2658 2658 2897 2897
17 444 444 887 887 1614 1614 2166 2166 2662 2662 2900 2900
19 458 453 890 890 1634 1634 2169 2169 2666 2666 2908 2908
21 1689 1009 2166 1627 2564 2215 2932 2790 3104 3068
23 3956 1738 3956 2207 4034 2703 4097 2957
15
3
15 875 875 1370 1370 1833 1833 2281 2281 2717 2717 2936 2936
17 877 877 1372 1372 1837 1837 2287 2287 2725 2725 2940 2940
19 1278 900 1546 1439 1868 1868 2291 2291 2728 2728 2947 2947
21 2877 1445 2869 1909 2916 2392 3045 2892 3135 3135
23 4468 1923 4464 2392 4449 2855 4445 3087
5
15 355 355 961 961 1526 1526 2021 2021 2490 2490 2721 2721
17 356 356 961 961 1528 1528 2025 2025 2494 2494 2725 2725
19 358 358 969 969 1532 1532 2029 2029 2502 2502 2728 2728
21 1603 979 1947 1547 2283 2108 2619 2619 2791 2791
23 3581 1605 3581 2071 3624 2552 3678 2802
7
15 70 70 444 444 922 922 1638 1638 2173 2173 2424 2424
17 70 70 444 444 922 922 1642 1642 2177 2177 2427 2427
19 70 70 444 444 926 926 1646 1646 2181 2181 2431 2431
21 460 445 953 953 1693 1693 2201 2201 2439 2439
23 1900 1032 2338 1626 2713 2199 2893 2481
COOLING CAPACITY - FCL72
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [w] = Total Cooling capacity
Ps [w] = Sensible Cooling capacity
Qv [m
3
/h] = Air flow rate
NB: the output values in bold type indicate the nominal value.
If sensible output values are above the total output, this means that
cooling is carried out without dehumidification.
If this occurs, take into consideration only the sensible output values.
The Cooling capacity of the table are at maximum speed (maximum
air flow). To determine the Cooling capacity based on the speed
(air flow), the values shown in the table must be multiplied by the
following factors (k):
FCL72
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4
900 11
Speed V3
680 0,75 0,73
Speed V2
520 0,61 0,57
Speed V1 (Minimum)
400 0,51 0,46
COOLING CAPACITY CORRECTION FACTORS
