AERMEC FCL 64 - Main Cooling Coil Pressure Drop (VL Version) - Cooling; Pressure Drops (Water 7°C)

47
IFCLTY 1112 - 4528511_04
MAIN COOLING COIL PRESSURE DROP [kPa] (VL version, without internal valve) - COOLING
Pressure drops [kPa] with water 7°C
Water fl ow rate [l/h] FCL32 FCL36 FCL42 FCL62 FCL72 FCL82 FCL102 FCL122
100 1,19 0,78 0,80
150 2,46 1,62 1,65 1,56 1,58
200 4,13 2,72 2,77 2,62 2,66
250 6,17 4,07 4,14 3,92 3,97 1,95
300 8,56 5,65 5,75 5,44 5,51 2,70
350 11,30 7,46 7,58 7,18 7,28 3,57 1,93 1,82
400 14,37 9,48 9,64 9,13 9,26 4,54 2,45 2,32
500 21,48 14,17 14,41 13,65 13,83 6,78 3,66 3,46
600 29,82 19,68 20,01 18,95 19,20 9,42 5,08 4,81
700 39,35 25,97 26,41 25,01 25,34 12,43 6,71 6,35
750 44,56 29,41 29,90 28,32 28,69 14,07 7,60 7,19
800 31,81 32,23 15,81 8,53 8,07
900 39,32 39,84 19,54 10,55 9,98
1000 47,53 48,16 23,62 12,75 12,06
1050 51,89 52,58 25,79 13,92 13,17
1100 28,04 15,14 14,32
1200 32,80 17,71 16,74
1300 37,88 20,45 19,34
1400 43,29 23,37 22,10
1500 49,01 26,46 25,02
1600 55,05 29,72 28,10
1700 61,39 33,14 31,34
1750 64,68 34,92 33,02
1800 36,73 34,74
1900 40,49 38,29
2000 44,40 41,99
2100 48,48 45,85
2200 52,71 49,85
2300 57,11 54,01
2400 61,65 58,30
2450 63,98 60,51
Pressure drops [kPa] with water 7°C
Water fl ow rate [l/h] FCL34 FCL38 FCL44 FCL64 FCL84 FCL104 FCL124
100 1,19 0,78 0,81
150 2,46 1,63 1,67 1,55
200 4,13 2,73 2,81 2,60
250 6,17 4,08 4,19 3,88 1,95 1,46 1,49
300 8,56 5,66 5,82 5,39 2,70 2,03 2,06
400 14,37 9,51 9,77 9,04 4,54 3,40 3,46
500 21,48 14,20 14,60 13,51 6,78 5,08 5,17
600 29,82 19,72 20,27 18,76 9,42 7,06 7,18
700 39,35 26,03 26,75 24,77 12,43 9,32 9,48
750 44,56 29,47 30,28 28,04 14,07 10,55 10,73
800 34,01 31,49 15,81 11,85 12,05
900 42,05 38,93 19,54 14,65 14,90
1000 50,83 47,06 23,62 17,70 18,01
1050 55,49 51,38 25,79 19,33 19,67
1100 55,87 28,04 21,02 21,38
1200 32,80 24,58 25,01
1300 37,88 28,39 28,88
1400 43,29 32,44 33,01
1500 49,01 36,73 37,37
1600 55,05 41,26 41,97
1700 61,39 46,01 46,81
1750 64,68 48,48 49,32
The pressure drops are calculated with the following formula:
DP = DP
rated
(Qw
rated
1.8
)*(Qw
1.8
)
The table shows the pressure drop for each size with fl ow rate
intervals of 50 and 100l/h
