51
IFCLTY 1112 - 4528511_04
Obligatory accessories, essential for unit operation.
The GLL, GLL_R and GLL_N range intake and delivery grille units with electric box are compulsory accessories as the FCL units
are dispatched without these components
(they also include the electrical box for the FCL).
NB>
* The GLL10 and GLL20 grille units have to be combined with an electronic or electromechanical standard control panel.
** Accessories that can only be used in combination with GLL10 and GLL20 grilles.
*** The GLLI10N and GLLI20N grille units have to be combined with a VMF range control panel (see VMF-E4 / VMF-E4D).
**** Up to three KFL20 or KFL20D devices can be assembled on a single unit (refer to the manual)
***** Requires GLL_M, GLL_R or GLL_N
(H)
Hot water circuit
(C)
Cold water circuit
Some accessories may not be applied at the same time on the same fan coil, while others need to be used with other
accessories and/or with a particular fan coil configuration.
Before placing an order, see documentation relating to all accessories and the fan coil.
FCL 32 34 36 38 42 44 62 64 72 82 84 102 104 122 124
Hot water circuit valve accessories for 4-pipe systems
(to combine with the provided control panels and the VMF System)
VHL1
(H)
✔✔✔✔
VHL20
(H)
✔✔✔
VHL2
(H)
✔✔✔✔
VHL22
(H)
✔✔✔
Electric resistor accessories
(to combine with the provided control panels and the VMF System)
RXLE**
✔✔✔✔✔
RXLE20**
✔✔✔
Accessories for VMF System (FCL with GLL_N grille)
Obligatory accessories, essential for unit operation.
The individual or network master units are required to be combined with the VMF-E4 / VMF-E4D control panel.
The Slave network units do not require the VMF-E4 / VMF-E4D control panel, they simply need to be connected (TTL) to the
Master unit.
Each network Master unit can have up to 5 Slave units connected to it.
The Master network units can be connected to a VMF-E5B or VMF-E5N main interface panel to manage the system.
The VMF system includes a variety of accessories and compositions. This table shows only the accessories designed for the opera-
tion of the units, for the selection refer to the compatibility table, the documentation of all the accessories and the fan coil.
VMF System control panel accessory (connected to the individual units or only to the Master units)
VMF-E4 ***
✔✔✔✔✔✔✔✔✔✔✔✔✔✔✔
VMF-E4D ***
✔✔✔✔✔✔✔✔✔✔✔✔✔✔✔
M
ain interface panel Accessory to manage the VMF System network (connected to the Master units)
VMF-E5B
✔
VMF-E5N
✔
Accessory water temperature probe for a 2-pipe system
SW4
(C) (H)
✔✔✔✔✔✔✔✔✔✔✔✔✔✔✔
Accessories water temperature probes for a 4-pipe system
VMF-SW1
(C)
✔✔✔✔✔✔✔✔✔✔✔✔✔✔✔
SW4
(H)
✔✔✔✔ ✔✔✔
