34. HYDRAULIC CONNECTIONS
Standard and OVERSIZED BATTERIES
BV HOT ONLY Coil
ATTENTION: -
•
seals.
To avoid drips during the cooling operation, it is
-
nections.
pipework with a spanner.
Standard coil attachments (female)
FCXI 20 30 - 36 40 50 - 56 80
1
/
2
”
1
/
2
”
3
/
4
”
3
/
4
”
3
/
4
”
Coil / heating only circuit attachments (female)
BV 122 132 142 142 162
1
/
2
”
1
/
2
”
1
/
2
”
1
/
2
”
1
/
2
”
Oversized coil attachments (female)
FCXI 24 34 44 54 84
3
/
4
”
3
/
4
”
3
/
4
”
3
/
4
”
3
/
4
”
FCXI 20 ÷ 56 FCXI 80 ÷ 84 BV + FCXI 20 ÷ 56 BV + FCXI 80
FCXI 20 ÷ 56 FCXI 80 ÷ 84 BV + FCXI 20 ÷ 56 BV + FCXI 80
