EN FR
19FCZI EUP 1906 _4033745_00
18
IFCXPLJ 1012 - 6456063_00
Installazione con supporti AMP (accessori) • Installation with AMP brackets (accessories)
Installation avec supports AMP (accessories) • Installation mit AMP halterung (zubehöre)
Instalación con soportes AMP (accesorios)
DATI DIMENSIONALI • DIMENSIONS • DIMENSIONS • ABMESSUNGEN • DIMENSIONES [mm]
FCX 17 - 22 - 32 - 42 - 50
24 - 34 - 44 - 54
FCX 62 - 82 -102
64 - 84
FCX (3R) 17 22 32 42 50 62 82 102
FCX (4R) - 24 34 44 54 64 84 -
B [mm] 445 555 786 1006 1006 1127 1127 1127
C [mm] 490 600 831 1051 1051 1172 1172 1172
FCX 17 ÷ 54 3R FCXI 62 - 102 3R FCX 17 ÷ 54 1R FCX 17 ÷ 54 1R
DATI DIMENSIONALI • DIMENSIONS • DIMENSIONS • ABMESSUNGEN • DIMENSIONES INC
FCZI 200 ÷ 500/ 250 ÷ 550
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
FCZ 62 ÷ 102 / 64 ÷ 84
INSTALLAZIONE CON SUPPORTI AMPZ ACCESSORI • INSTALLATION WITH AMPZ BRACKETS ACCESSORIES
INSTALLATION AVEC SUPPORTS AMPZ ACCESSORIES • INSTALLATION MIT AMPZ HALTERUNG ZUBEHÖRE
INSTALACIÓN CON SOPORTES AMPZ ACCESORIOS
A
D
B
C
FCZI_EUP / PO / PPC 200 201 202 250 300 301 302 350 400 401 402 450 500 501 502 550
Altezza•Height•Hauteur Höhe•altura A inch 17,83 17,83 17,83 17,83
Larghezza•Width Largeur•Breite•Ancho
B* inch 31,22 31,22 33,88 33,88
D inch 20,55 29,69 38,30 38,30
Profondità•Depth profondeur•
Tiefe•profundidad
C inch 8,50 8,50 8,50 8,50
Peso•Weight•Poids•Gewicht•
Peso
Lb 26,45 28,66 30,86 30,86 30,86 33,06 35,27 35,27 44,09 46,29 48,50 48,50 50,70 50,70 52,91 52,91
FCZI_EUP / PO / PPC 700 701 702 750 900 901 / 950
Altezza•Height•Hauteur Höhe•altura A mm 17,83 21,96
Larghezza•Width Largeur•Breite•Ancho
B* mm 45,15 45,15
D mm 44,17 44,17
Profondità•Depth profondeur•
Tiefe•profundidad
C mm 8,50 8,50
Peso•Weight•Poids•Gewicht•
Peso
Lb 57,32 59,52 61,72 61,72 70,54
FCZI 700 ÷ 900 / 750
1,41
4,13 10,15
3,93
0,19 0,19
10,15
Installazione sonda acqua - Water Probe installation
Installation du la sonde d'eau - Wassersensor Installation
La instalación del sensor de agua
1
2
3
Collegamenti elettrici - Electric connections - Branchements Électri-
ques - Elektrische anschlüsse - Conexiones eléctricas
