40
FUNZIONAMENTO
OPERATION
rata, che la temperatura dell’ acqua in circolazione scenda
sotto i 40 °C.
A questo punto si mettano in funzione i ventilconvettori: il
progettista o l’installatore potranno fornire informazioni sul
numero massimo di questi che possono funzionare contem-
poraneamente (potrebbero essere tutti quelli installati o solo
alcuni: dipende dai carichi termici relativi ai vari ambienti).
Se si mettessero in funzione più ventilconvettori di quanto
consentito, il modulo ID non riuscirebbe a raffreddare com-
pletamente l’acqua in circolazione, e gli ambienti asserviti
subirebbero un raffrescamento parziale. L’Idrosplit avverte
l’utente di questa situazione tramite l’accensione della spia
di sovraccarico (si veda più sotto).
FUNZIONAMENTO INVERNALE
Si richiamano qui le operazioni da eseguire per commutare
da funzionamento estivo ad invernale, rimandando per ogni
altra informazione alle istruzioni d’uso allegate alla caldaia.
Per predisporre il Sistema Idrosplit in funzionamento inver-
nale (distribuzione di acqua calda ai ventilconvettori) agire
come segue:
- accertarsi che il circuito idraulico non sia intercettato in nes-
sun punto, e che quindi l’acqua possa circolare liberamente;
- verificare che il modulo ID sia spento (interruttore 1 di fig.
14 in posizione “zero”);
- accendere la caldaia in funzionamento invernale, facendo
riferimento alle istruzioni a corredo.
Certi modelli di caldaie possono entrare in blocco nel caso
in cui, per una manovra errata, vengano accesi contempo-
raneamente il modulo ID e la caldaia in funzionamento
invernale, perchè ID blocca il flusso dell’acqua calda.
Consultare le istruzioni a corredo della caldaia per le opera-
zioni di sblocco. È comunque possibile evitare il verificarsi
di tale eventualità facendo riferimento al capitolo
“Collegamenti Elettrici”.
Altre cause che possono provocare il blocco della caldaia
ed i relativi rimedi sono descritte nel libretto istruzioni alle-
gato all’apparecchio.
REGOLAZIONE TEMPERATURA ACQUA FREDDA.
All’accensione del modulo ID, la temperatura dell’acqua di
ritorno dall’impianto (prima cioè che essa subisca il raffred-
damento e venga inviata ai ventilconvettori), viene automa-
ticamente impostata a 10 °C; questa temperatura è normal-
mente sufficiente a garantire il buon funzionamento
dell’impianto di condizionamento. È possibile comunque
regolare la temperatura dell’acqua di ritorno da 9 a 20 °C
effettuando le seguenti operazioni:
- tenere premuto il pulsante (2) di fig. 14, contrassegnato
con il “cacciavite”; sul display viene visualizzata la tem-
peratura impostata in precedenza;
- impostare la temperatura dell’acqua di ritorno per mezzo
dei tasti (4). Usare il tasto superiore per aumentare la tem-
peratura e quello inferiore per diminuirla;
- rilasciare il pulsante (2).
REGOLAZIONE TEMPERATURA ACQUA DI RISCALDAMENTO
Per il funzionamento con ventilconvettori, si consiglia una
temperatura dell’acqua di mandata di circa 50 °C.
Per la regolazione della temperatura, si faccia riferimento
alle istruzioni della caldaia.
In fig. 14 è riportato il pannello comandi del modulo ID. Il
pannello è dotato dei seguenti comandi e segnalazioni:
- interruttore (1) acceso-spento; svolge anche la funzione di
pulsante di sblocco in caso di intervento delle sicurezze;
- pulsante (2) per la visualizzazione o la modifica della
temperatura di funzionamento impostata (set-point);
ler can provide information on the maximum number of
these that can operate simultaneously (it could be all those
installed or only some: it depends on the thermal loads in
the various rooms). If more fancoils start than permitted, the
ID module would not be able to completely chill the water
in circulation, and the rooms served would only be partially
cooled. Idrosplit warns the user of this situation by lighting
up the overload pilot light (see below).
WINTER OPERATION
Here we recall the operations to perform when commuting
from summer to winter operation, leaving any other infor-
mation to the boiler’s user instructions.
To set the Idrosplit System in winter operation (distribution
of hot water to fancoils) proceed as follows:
- check that the hydraulic circuit has not been shut-off at
any point, so that the water can circulate freely
- check that the ID module is turned off (switch 1 in fig. 14,
set to “zero”)
- turn the boiler to winter operation, consulting the boiler
user instructions
Certain models will enter a block in the case where, for a
wrong manoeuvre, they are turned on simultaneously with
the ID module and the boiler in winter operation, because
the ID blocks the water flow. Consult the boiler instructions
for the resetting operations. It is nevertheless possible to
avoid the arising of this eventuality referring to the chapter
“Wiring Connections”.
Other causes can provoke the boiler to block and relative
remedies are described in the instruction booklet attached
to the appliance.
CHILLED WATER TEMPERATURE ADJUSTMENT
On turning on the ID module, the temperature of water
returning from the plant (i.e. before it is subjected to cooling
and is sent to the fancoils), is automatically set at 10°C. This
temperature is normally sufficient to guarantee the correct
operation of the air-conditioning plant. However, it is possi-
ble to adjust the return water temperature from 9 to 20°C,
by carrying out the following operations:
- keep button (2) pressed in fig. 14, marked with the
“screwdriver” decal, the display shows the current tempe-
rature setting;
- set the return water temperature with the keys (4). Use the
top key to increase the temperature and the bottom key to
reduce it;
- release button (2).
HEATING WATER TEMPERATURE ADJUSTMENT
To operate the fancoils, we recommend a delivery tempera-
ture of the water of about 50°C.
To adjust the temperature, consult the boiler instruction
manual.
Fig. 14 illustrates the ID module’s control panel. The panel
is fitted with the following controls and pilot lights:
- on/off switch (1). This also acts as the reset button in case
of safety trips;
- button (2) to display or adjust the set operating temperatu-
re (set-point);
BLOCCO DELLA CALDAIA •
BOILER ALARM BLOCK
REGOLAZIONE TEMPERATURA ACQUA •
WATER TEMPERATURE ADJUSTEMENT
PANNELLO COMANDI •
CONTROL PANEL
