AERMEC NLC 0280H - Antivibration

22.05  4037365_03 35
Size 0280 0300 0330 0350 0550 0600 0650 0675 0750 0800 0900 1000 1100 1250
2 A % 9% 10% 10% 10% 15% 17% 17% 18% 10% 10% 10% 11% 11% 11%
3 A % 23% 23% 23% 23% 19% 19% 19% 19% 8% 8% 7% 7% 7% 7%
4 A % 17% 17% 17% 17% 19% 19% 20% 20% 7% 8% 7% 7% 7% 7%
5 A % 22% 21% 21% 21% 16% 14% 13% 13% 10% 10% 11% 11% 11% 11%
6 A % 16% 16% 16% 16% 16% 15% 14% 14% 9% 9% 11% 10% 11% 11%
7 A % - - - - - - - - 13% 13% 13% 12% 13% 12%
8 A % - - - - - - - - 12% 12% 12% 12% 13% 12%
9 A % - - - - - - - - 10% 10% 9% 9% 8% 8%
10 A % - - - - - - - - 10% 9% 9% 9% 8% 8%
INTEGRATED HYDRONIC KIT: P1, P3
Centre of gravity (during operation)
X A in 43.9 42.9 42.6 42.5 57.4 55.0 55.0 53.9 120.2 119.5 121.5 117.6 118.7 117.4
Y A in 16.6 16.3 16.7 16.6 20.8 20.4 20.3 20.2 21.6 22.0 21.8 21.5 21.3 21.2
Weight distribution in % on the supports (during operation)
1 A % 30% 30% 31% 31% 26% 27% 27% 27% 13% 13% 13% 14% 14% 14%
2 A % 27% 29% 28% 28% 29% 30% 31% 31% 13% 13% 13% 14% 14% 14%
3 A % 22% 21% 21% 21% 22% 20% 20% 19% 11% 11% 10% 10% 10% 9%
4 A % 20% 20% 20% 20% 23% 22% 23% 22% 11% 11% 10% 10% 10% 10%
5 A % - - - - - - - - 15% 15% 17% 16% 16% 16%
6 A % - - - - - - - - 15% 15% 17% 16% 16% 17%
7 A % - - - - - - - - 11% 11% 11% 10% 10% 10%
8 A % - - - - - - - - 11% 10% 10% 10% 11% 10%
9 A % - - - - - - - - - - - - - -
10 A % - - - - - - - - - - - - - -
INTEGRATED HYDRONIC KIT: P2, P4
Centre of gravity (during operation)
X A in 45.8 44.8
44.5 44.5 59.1 56.7 56.9 55.7 122.7 121.9 124.1 120.2 122.3 121.0
Y A in 17.0 16.7 17.0 17.0 20.9 20.5 20.3 20.2 21.6 22.0 21.8 21.5 21.3 21.2
Weight distribution in % on the supports (during operation)
1 A % 29% 29% 30% 30% 26% 26% 26% 27% 13% 13% 12% 14% 13% 14%
2 A % 26% 27% 27% 27% 28% 29% 30% 30% 13% 13% 12% 14% 14% 14%
3 A % 24% 23% 23% 23% 23% 21% 21% 20% 11% 11% 10% 10% 9% 9%
4 A % 21% 21% 21% 21% 24% 23% 24% 23% 11% 11% 10% 10% 9% 9%
5 A % - - - - - - - - 15% 15% 17% 16% 16% 16%
6 A % - - - - - - - - 15% 14% 16% 16% 16% 16%
7 A % - - - - - - - - 12% 12% 11% 11% 12% 11%
8 A % - - - - - - - - 12% 11% 11% 11% 12% 12%
9 A % - - - - - - - - - - - - - -
10 A % - - - - - - - - - - - - - -
ANTIVIBRATION
VT
Ver 0280 0300 0330 0350 0550 0600 0650
Integrated hydronic kit: 00
A VT17 VT17 VT17 VT17 - - -
Integrated hydronic kit: 01, 02, 03, 04
A VT11 VT11 VT11 VT11 - - -
Integrated hydronic kit: P1, P2, P3, P4
A VT13 VT13 VT13 VT13 - - -
The accessory cannot be tted on the congurations indicated with -
AVX
Ver 0280 0300 0330 0350 0550 0600 0650
Integrated hydronic kit: 00, P1, P2, P3, P4
A - - - - AVX410 AVX410 AVX410
Integrated hydronic kit: 01, 02, 03, 04
A - - - - AVX412 AVX412 AVX412
The accessory cannot be tted on the congurations indicated with -
Ver 0675 0750 0800 0900 1000 1100 1250
Integrated hydronic kit: 00
A AVX410 AVX432 AVX432 AVX432 AVX432 AVX432 AVX431
Integrated hydronic kit: 01, 02, 03, 04
A AVX412 AVX436 AVX436 AVX436 AVX436 AVX436 AVX436
Integrated hydronic kit: P1, P3
A AVX410 AVX432 AVX432 AVX432 AVX432 AVX432 AVX433
Integrated hydronic kit: P2, P4
A AVX410 AVX432 AVX432 AVX432 AVX432 AVX433 AVX433
