MINIMUM TECHNICAL SPACES
* Minimum technical space, to be ensured in order for the chiller to work properly and for possible maintenance. ATTENTION: with this space, the condenser coil can
only be pulled out from above, see gures on the next page; to pull it out from the side you must leave at least 91 in.
Unit Vers. V-blok Fans Panel type A B C D E
NRB n° n° mm mm mm mm mm
800 A 2 4 1 39* 43 39* 32 118
900 A 2 4 1 39* 43 39* 32 118
1000 A 3 6 1 39* 43 39* 32 118
1100 A 3 6 1 39* 43 39* 32 118
1200 A 3 6 1 39* 43 39* 32 118
1400 A 3 6 1 39* 43 39* 32 118
1600 A 4 8 1 45* 43 45* 32 118
1800 A 4 8 1 45* 43 45* 32 118
2000 A 5 10 1 45* 43 45* 32 118
2200 A 5 10 1 45* 43 45* 32 118
2400 A 6 12 1 45* 43 45* 32 118
2600 A 7 14 1 45* 43 45* 32 118
2800 A 7 14 1 58* 43 58* 32 118
3000 A 7 14 1 58* 43 58* 32 118
800 E 4 8 1 39* 43 39* 32 118
900 E 4 8 1 39* 43 39* 32 118
1000 E 5 10 1 39* 43 39* 32 118
1100 E 6 12 1 45* 43 45* 32 118
1200 E 6 12 1 45* 43 45* 32 118
1400 E 7 14 1 45* 43 45* 32 118
1600 E 7 14 1 45* 43 45* 32 118
1800 E 8 16 1 45* 43 45* 32 118
2000 E 8 16 1 45* 43 45* 32 118
2200 E 8 18 1 45* 43 45* 32 118
2400 E 10 20 1 45* 43 45* 32 118
2600 E 10 20 1 45* 43 45* 32 118
2800 E 10 20 1 58* 43 58* 32 118
3000 E 9 18 1 58* 43 58* 32 118
800 U 4 8 1 39* 43 39* 32 118
900 U 4 8 1 39* 43 39* 32 118
1000 U 5 10 1 39* 43 39* 32 118
1100 U 6 12 1 45* 43 45* 32 118
1200 U 6 12 1 45* 43 45* 32 118
1400 U 7 14 1 45* 43 45* 32 118
1600 U 7 14 1 45* 43 45* 32 118
1800 U 8 16 1 45* 43 45* 32 118
2000 U 8 16 1 45* 43 45* 32 118
2200 U 9 18 1 45* 43 45* 32 118
2400 U 10 20 1 45* 43 45* 32 118
2600 U 10 20 1 45* 43 45* 32 118
2800 U 10 20 1 58* 43 58* 32 118
3000 U 9 18 1 58* 43 58* 32 118
800 N 5 10 1 45* 43 45* 32 118
900 N 5 10 1 45* 43 45* 32 118
1000 N 6 12 1 45* 43 45* 32 118
1100 N 7 14 1 45* 43 45* 32 118
1200 N 7 14 1 45* 43 45* 32 118
1400 N 8 16 1 45* 43 45* 32 118
1600 N 8 16 1 45* 43 45* 32 118
1800 N 9 18 1 45* 43 45* 32 118
2000 N 9 18 1 45* 43 45* 32 118
2200 N 10 20 1 45* 43 45* 32 118
2400 N 11 22 1 45* 43 45* 32 118
2600 N 11 22 1 45* 43 45* 32 118
2800 N 11 22 1 58* 43 58* 32 118
3000 N 10 20 2 58* 32 58* 32 118
