AERMEC NRK 0150 A - Position of Hydraulic Connections

21.05 – 5167557_02 15
POSITION OF HYDRAULIC CONNECTIONS
NRK 0150 A (00-01-03-P1-P3) NRK 0300 A (00)
NRK 0300 A (01-04) NRK 0300 A (P1-P4)
COMPONENTS SUPPLIED AS STANDARD (FOR SIZES 0300-0330-0350-0550-0600-0650-0700 )
Grooved joints EU Grooved joint USA Grooved nipple USA
Reduction/adapter EU-USA
IN Water 1"1/4
OUT Water 1"1/4
29.6 in
29.6 in
5.5 in
4.0 in
20.4 in
43.3 in
9.7 in
13.6 in
22.8 in
43.3 in
9.7 in
13.6 in
16.9 in
43.3 in
9.7 in
13.6 in 27.8 in
3.9 in
0.6 in 0.6 in
0.3 in 0.3 in
0.1 in
0.1 in
