AERMEC NRL - Page 31

NRL 2800 3000
COMPRESSOR THERMOMAGNETIC SWITCHES 400V CIRCUIT 1° CIRCUIT 2° CIRCUIT 1° CIRCUIT 2°
MTC1 62A 62A 51A 51A
mtc1a 62A 62A 51A 51A
mtc1b - - 51A 51A
mtc2 51A 51A 51A 51A
mtc2a 51A 51A 51A 51A
mtc2b 51A 51A 51A 51A
HIGH PRESSURE SWITCH WITH MANUAL RESET
PA (bar)
40 40
High pressure transducer
TAP (bar) 39 39
LOW PRESSURE TRANSDUCER
TBP (bar) 22
CHILLER CIRCUIT SAFETY VALVE
AP (bar) 45 45
BP (bar) only in heat pump 30 30
FANS THERMOMAGNETIC SWITCHES [°]
The calibration is carried out on a thermomagnetic switch (single ventilation line)
Fans °/L 7A 7A 7A 7A
Fans H°/HL 9A 9A 9A 9A
FANS THERMOMAGNETIC SWITCHES [M]
The calibration is carried out on a thermomagnetic switch (single ventilation line)
Fans °/L 7A 7A 7A 7A
Fans H°/HL 9A 9A 9A 9A
NUMBER OF FANS
No. fans °/L 4444
No. fans H/HL 4444
NRL 3300 3600
COMPRESSOR THERMOMAGNETIC SWITCHES 400V CIRCUIT 1° CIRCUIT 2° CIRCUIT 1° CIRCUIT 2°
MTC1 51A 51A 62A 62A
mtc1a 51A 51A 62A 62A
mtc1b 51A 51A 62A 62A
mtc2 62A 62A 62A 62A
mtc2a 62A 62A 62A 62A
mtc2b 62A 62A 62A 62A
HIGH PRESSURE SWITCH WITH MANUAL RESET
PA (bar) 40 40
High pressure transducer
TAP (bar) 39 39
LOW PRESSURE TRANSDUCER
TBP (bar) 22
CHILLER CIRCUIT SAFETY VALVE
AP (bar) 45 45
BP (bar) only in heat pump 30 30
FAN THERMOMAGNETIC SWITCHES [°]
The calibration is carried out on a thermomagnetic switch (single ventilation line)
Fans °/L 11A 11A 11A 11A
Fans H°/HL 13A 13A 13A 13A
FANS THERMOMAGNETIC SWITCHES [M]
The calibration is carried out on a thermomagnetic switch (single ventilation line)
Fans °/L 13A 13A 13A 13A
Fans H°/HL 18A 18A 18A 18A
NUMBER OF FANS
No. fans °/L 13A 13A 13A 13A
No. fans H/HL - - - -
31
INRLPY. 02.10 4086916_01
