AERMEC NXP 0700 - Hydraulic Circuit Diagrams

17
IN
OUT
OUT
IN
IN
OUT
EV
RCCN
IN
OUT
OUT
IN
IN
OUT
EV
RCCN
HYDRAULIC CIRCUITS
NXP 0500÷0750 (°)
NXP 0800÷1650 (°) NXP 0800÷1650 (L)
NXP 0500÷0750 (L)
Key
EV Exchanger side (hot/cold)
RC Exchanger side (DHW)
CN Exchanger side (geothermal)
Hydraulic connection (grooved joints)
Ø 2”1/2 (76,1mm)
Ø 2”1/2 (76,1mm)
Ø 3” (88,9mm)
Ø 3” (88,9mm)
