64
219 Top part timer, condenser pumps 1 --- R
220 Top part timer, comp.1 circ.1 --- R
221 Bottom part timer, comp.1 circ.1 --- R
222 Top part timer, comp.2 circ.1 --- R
223 Bottom part timer, comp.2 circ.1 --- R
224 Top part timer, comp.3 circ.1 --- R
225 Bottom part timer, comp.3 circ.1 --- R
226 Top part timer, comp.1 circ.2 --- R
227 Bottom part timer, comp.1 circ.2 --- R
228 Top part timer, comp.2 circ.2 --- R
229 Bottom part timer, comp.2 circ.2 --- R
230 Top part timer, comp.3 circ.2 --- R
231 Bottom part timer, comp.3 circ.2 --- R
232 Thermostat % R
233 Modulating pump evaporator R
234 Modulating pump condenser R
235 Fan speed 1 (0..1000) --- R
236 Fan speed 2 (0..1000) --- R
237 Top part timer, evaporator pumps 2 --- R
238 Bottom part timer evaporator pumps 2 --- R
239 Bottom part timer condenser pumps 2 --- R
240 Top part timer condenser pumps 2 --- R
241 Actual Power Capacity % R
414 Limit (0-100%) (the multifunction input from B8 input must be disabled) % R/W
415 Demand (0-100%) (the multifunction input from B8 input must be disabled) (the
digital address 7 must be enabled)
% R/W
Digital variables
BMS Address Description UOM Direction
1 Unit On/Off control (delayed by 120 sec) --- R/W
2 Summer/winter (0=cold water prod.) --- R/W
3 Reset alarms (1= reset) --- R/W
4 Unit switch-on request from digital input --- R
5 System cold/hot request from digital input --- R
6 On/Off status --- R
7 Enables thermostat from BMS --- R/W
30 Evaporative pump 1 --- R
31 Evaporative pump 2 --- R
32 Condenser pump 1 --- R
33 Condenser pump 2 --- R
36 CCP1 - Compressor 1 circ.1 --- R
37 CCP1A - Compressor 2 circ.1 --- R
39 CCP2 - Compressor 1 circ.2 --- R
40 CCP2A - Compressor 1 circ.2 --- R
42 CV - Fan 1 --- R
43 CV1 - Fan 2 --- R
44 VIC- cycle reversing valve, Circ 1 --- R
45 VIC- cycle reversing valve, Circ 2 --- R
46 VS1 - liquid solenoid valve 1 circ.1 --- R
