NOTE
Not all alarms will be visible, but depending on the type of machine.
ALARMS summary table
Alarm code Rearm Description
AL106
pCOe number 2: I/O mismatch alarm (no confirmation of pattern for 10s)
(DK version Probes expansion)
Analog variables
BMS Address Description UOM Read/Write
1 SUW - Evap. outlet temp. 1 °C R
2 SUW - Evap. inlet temp. 1 °C R
3 Outlet water condenser temp. °C R
4 Inlet water condenser temp. °C R
5 SUR1 - Circ.1 recovery outlet temp. °C R
6 SIR - Recovery inlet temp. °C R
7 TAP1 - Circ.1 high pressure BarG R
8 TBP1 - Circ.1 low pressure BarG R
9 TAP2 - Circ.2 high pressure BarG R
10 TBP2 - Circ.2 low pressure BarG R
11 TAE - External air temp. 1 °C R
16 Defrost battery temp circuit 1 °C R
17 Defrost battery temp circuit 2 °C R
18 Actual setpoint °C R
19 Multifunction input --- R
20 Circuit 2 total recovery outlet water temperature (only DK units) °C R
21 Common total recovery outlet water temperature (only DK units) °C R
22 SUW2 - Evaporator 2 water outlet probe (only DK units) °C R
23 SUCE - Evaporators common outlet probe (only DK units) °C R
24 SUWH2 - Condenser 2 outlet probe (only DK units) °C R
25 SUCC - Condensers common outlet probe (only DK units) °C R
201 Total recovery differential °C R/W
202 System summer differential °C R/W
203 System winter differential °C R/W
204 Set point 1, summer °C R/W
205 Set point 2, summer °C R/W
206 Set point 1, winter °C R/W
207 Set point 2, winter °C R/W
Integer variables
BMS Address Description UOM Direction
209 Chiller Mode State: Heat = 1 , Cool =2 R
210 Chiller Mode Request: Heat = 1 , Cool =2 R/W
216 Top part timer, evaporator pumps 1 --- R
217 Bottom part timer evaporator pumps 1 --- R
218 Bottom part timer condenser pumps 1 --- R
