36
mm
ULI 16 C ULI 26 C ULI 36 C
A 750 980 1200
B 494 725 945
C 470,5 701,5 921,5
D 398 629 849
E 504 735 955
1
2 Mobile di copertura • Cabinet • Meuble de couverture • Gehäuse
3 Struttura portante • Bearing structure • Structure portante • Trägerstruktur
4 Zoccolo ZU • Feet ZU • Pieds ZU • Sockel ZU
5 Spazio per i collegamenti • Free space available for connection • Espace puor branchements • Raum für die Anschlüsse
