26
4238010_00 - 0912
2
Open the control panel to be able to
fix onto the recessed electrical wall box
WARNING: After having opened the
control panel do not touch the circuit
board with bare hands to avoid dam-
age from accidental static discharge
3
Connect the terminal to the control panel
4
Fix the control panel to the recessed box
5
Close the control panel
