47
IVEDLJ 1107 - 4880900_01
DIMENSIONI [mm]
Ø16
1509
1504
789
150
440
174
25
1558
1533
1453
40
40
329
423
280
316
351
307
109
379
15
326
247
287
46
10
20
VED 630 - 640 - 730 -740 - 632 - 641 - 732 - 741
VED 630 640 730 740 632 641 732 741
Attacchi idraulici batteria principale (femmina)
Main coil water connections (female)
Raccords hydrauliques de la batterie principale (femelle)
Wasseranschlüsse für Hauptwärmetauscher
(Innengewinde)
Conexiones hidráulicas batería principal (hembra)
Ø 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G 3/4"G
Attacchi idraulici batteria per solo riscaldamento (femmina)
Heating only coil water connections (female)
Raccords hydrauliques de la batterie pour chauffage
seul (femelle)
Wasseranschlüsse für Wärmetauscher für reinen
Heizbetrieb (Innengewinde)
Conexiones hidráulicas batería sólo calor (hembra)
Ø----1/2"G 1/2"G 1/2"G 1/2"G
Attacchi scarico condensa (diametro esterno)
Condensate discharge connections (external diameter)
Raccords d'évacuation des condensats (diamètre extérieur)
Anschlüsse für Kondensatablass (Außendurchmesser)
Conexiones de descarga de condensación (diámetro exterior)
mm 16 16 16 16 16 16 16 16
