D. Modulation Meter Screen (cont)
SCREEN FEATURE FUNCTION
State - Upper Limit Used to display the Upper Limit Marker on the Modulation Meter Bar.
Select: On or Off
Modulation Meter Bar A graphical representation of the received Modulation Meter readings.
F1 “Edit” / “Done” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
F2 “Save” Performs a data dump of frames displayed on the screen, including
configurations, readings and settings. The data dump is stored in a
time-stamped ASCII report and can be retrieved at a later time.
F3 “Hold” / “Resume” Hold Freezes the screen.
Resume Restores the screen to active mode.
F5 “Return” / “Esc” Return Closes the Modulation Meter Screen and returns to the Test
Screen.
Esc Ends the Field Edit, but does NOT save any changes to the
setting or value.
