2-2-2. SYSTEM MENU
When the unit is powered ON, the System Menu is displayed, or when the Meters Menu, Self Test
Menu or Utilities Menu is displayed, press the F3 “System” Key to access the System Menu:
Me ter s System Self test Uti l
1 - DUPLEX TEST
2 - RE CEI VER TEST
3 - TRANSMITTER TEST
4 - ANT-CABLE TEST
5 - AUDIO
SCREEN FEATURE FUNCTION
1 - DUPLEX TEST Displays the Duplex Test Screen (para 2-2-2A).
2 - RECEIVER TEST Displays the Receiver Test Screen (para 2-2-2B).
3 - TRANSMITTER TEST Displays the Transmitter Test Screen (para 2-2-2C).
4 - ANT-CABLE TEST Displays the ANT-Cable Test Screen (para 2-2-2D).
5 - AUDIO Displays the Audio Test Screen (para 2-2-2E).
F2 “Meters” Displays the Meters Menu (para 2-2-3).
F3 “System” Displays the System Menu (para 2-2-2).
F4 “Selftest” Displays the Self Test Menu (para 2-2-4).
F5 “Util” Displays the Utilities Menu (para 2-2-5).
