Subject to Export Control, see Cover Page for details. 2-35
D. ANT-Cable Test Screen (cont)
SCREEN FEATURE FUNCTION
F5 “Marker” / “Scale”
“Cable” / “RF” / “Esc”
Marker Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to Marker Mode.
Scale Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to Scale Mode.
Cable Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to Cable Mode.
RF Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to RF Mode.
Esc Ends the Field Edit, but does NOT save any changes to
the setting or value.
