2-36 Subject to Export Control, see Cover Page for details.
D. ANT-Cable Test Screen (cont)
ANT-CABL E TEST
0.0 0
2009-06 -25
11:35:30
dB
-50.0
0. 1 Ft 415.5
Cable: USER Velocity: 0.66 Loss: 3. 00
Est Length: 415.5 Unit Feet
Edit Return
Ho l d
Cal
Scale
41 20 29
(DTF - Cable Mode)
SCREEN FEATURE FUNCTION
VSWR Progress Bar A graphical representation of the percentage completed for the
current measurement.
Cable Used to select the type of coaxial cable used on the system under
test.
Select: RG-400, RG-223, RG-214, RG-213, RG-174, RG-58C,
RG-58B, RG-58A, RG-58foam, RG-58, RG-55B, RG-55A,
RG-55, RG-8A, RG-8foam, RG-8, RG-8x or USER.
Velocity Used to select the velocity of the propergation (Vp) factor for the
cable selected.
Select: 0.0 to 1.0 in 0.01 increments
Loss Used to select the cable insertion loss per 100 ft for the cable
selected.
Select: 0.00 to 100.00 in 0.01 increments
Est Length Used to select the estimated length of the cable under test.
Select: 42.0 to 619.4 ft in 0.1 ft increments.
12.8 to 304.8 m in 0.1 m increments
When an estimated length is entered, the frequency span adjusts to
the correct level automatically.
Unit Used to select the units of measure.
Select: Feet or Meters
