D. ANT-Cable Test Screen (cont)
SCREEN FEATURE FUNCTION
F1 “Edit” / “Done” / “Next” Edit Highlights the selected field to be changed or changes the
field value if the field only contains two selections.
Done Ends the Field Edit and saves the new setting / value.
Next Displays the next pop-up screen.
F2 “Return” / “Save” Return Displays the System Menu (para 2-2-2)
Save Performs a data dump of frames displayed on the screen,
including configurations, readings and settings. The data
dump is stored in a time-stamped ASCII report and can be
retrieved at a later time.
F3 “Hold” / “Resume” /
“Abort”
Hold Freezes the screen.
Resume Restores the screen to active mode.
Abort Stops the action to calibrate the SWR Connector.
F4 “Cal” Instruction pop-ups are displayed to calibrate the SWR Connector.
F5 “Marker” / “Scale”
“RF” / “Esc”
Marker Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to Marker Mode.
Scale Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to Scale Mode.
RF Used to change the displayed fields and functionality
on the ANT-Cable Test Screen to RF Mode.
Esc Ends the Field Edit, but does NOT save any changes to
the setting or value.
