9
¾ Press shearing head lock 13, see Fig. 4.
Fig. 5
¾ Fold forward shearing head 12, see Fig. 5.
¾ Detach shearing head 12.
¾ Clean open knife hinge with a brush.
¾ Install shearing head on knife hinge 12.
¾ Press on/off switch 11.
¾ Press shearing head 12 slightly in the direction of
the DURATI battery-powered shearing.
Shearing head 12 will audibly click into position.
¾ Check that the shearing head 12 is correctly seated
on the DURATI battery-powered shearing machine.
5.4.3 Lubricating the shearing head
¾ Clean upper cutting plate and lower cutting plate
with a soft wipe or brush. Make certain the gaps in
serration are cleaned properly.
¾ Slightly lubricate upper cutting plate and lower
cutting plate with special lubricant for shearing
heads GT604.
5.4.4 Li-ion battery
Fig. 6
¾ Hold DURATI battery-powered shearing machine 2
and press battery release lock 3.
¾ Pull out Li-ion battery 7 from DURATI battery-
powered shearing machine 2.
¾ Insert the charged Li-ion battery 7 in DURATI bat-
tery-powered shearing machine 2 as far as it will
go.
The DURATI battery-powered shearing machine 2
is ready for operation.
6. Reprocessing
2
12
CAUTION
Damage to, or destruction of the
product caused by mechanical
cleaning/disinfecting or steriliza-
tion!
¾ Only clean and disinfect the
product manually.
¾ Do not sterilize the product
under any circumstances.
8
3
2
3
