AFi NANTUCKET MURPHY - STRUCTURAL PANEL INSTALLATION

Adult assembly
Page 3 of 8
08
03
04
06
B
B
B
B
B
B
JCB M6 X 25mm
Allen wrench
B
K
Adult assembly
STEP 2
Attach left and right side panels (03) and (04) to the drawer base (0 ) as shown below.
Using JCB (B) tighten with Allen wrench (K)
8
NANTUCKET MURPHY BED
WITH CHARGING STATION
STEP 3
Guide the back panel (0 ) in carefully so that it won’t jump out of its grooves. Be sure
it fits fully into its groove at the .
6
top panel base
TWIN
