AFi NANTUCKET MURPHY - FOLDING MECHANISM AND MATTRESS INSTALLATION

Page 7 of 8
I
I
J
J
STEP 10
NANTUCKET MURPHY BED
WITH CHARGING STATION
STEP 11
Attach triangle bracket (I) to the back of cabinet as shown below. Use wood screw (J)
tighten with Phillips head screwdriver. (customer supplied).
Triangle bracket
Wood Screw 1”
I
J
Adult assembly
TWIN
Pull the drawer out fully. Unlatch the door and open, folding down as shown.
Open
Adult assembly
