10. Control and Electronics system fault troubleshooting
10.1 General control system and Front Board Troubleshoots
The front board is the center of all peripheral functions of the scooter: Lights , Horn ,
Information goes to the LEDS on the display .
Elimination troubleshoots:
The Front Board wiring connections are all quick connectors.
If you suspect the Front Board to be faulted we recommend as a quickest way to find if the
Front Board is faulty, Doing by elimination – Just replace temporarily the Front Board with
another working one and thus make sure if the problem is within the Front Board or
somewhere else.
Check all connection of the Front Board, following the wiring diagram that can be found at the
end chapter of this maintenance manual.
Check main and Charge fuse, located under the seat.
Also always check related function switch , as an example Light does not work , first check the
light switch for continuity ,when it is in ON position. Use the wiring diagram to figure the proper
terminals to check each function switch terminals.
Trouble Shoot Table:
#
Description
Probable cause
Repair action
1
Front light doesn't work
Front LED board faulty
Replace front LED board
Front Board faulty
Replace Frond Board
2
Front Blinker/s doesn't work
Front Blinker board faulty
Replace front Blinker board
Front Board faulty
Replace Frond Board
3
Rear pilot/s light does work
Rear Blinker board faulty
Replace Rear Blinker board
Front Board faulty
Replace Frond Board
4
Rear Blinker/s doesn't work
Rear Blinker board faulty
Replace Rear Blinker board
Front Board faulty
Replace Frond Board
5
Horn does not work properly
Horn is faulty
Replace Horn
Horn is faulty
Replace Frond Board
Front Board faulty
Replace Frond Board
6
Hazard doesn't work
Hazard switch fault
Check switch and repair
Front Board faulty
Replace Frond Board
7
Reverse function doesn't work
Reverse switch fault
Check switch and repair
Front Board faulty
Replace Frond Board
8
Electric EMB release function
does not work
EMB release Switch
faulty
Check switch and repair
10
No Charge start
Charger fault
Replace charger
Charge fuse popup or
faulty
Reset /Replace charge fuse
11
Travel distance very low
Charger fault
Replace charger
Old / Weak batteries
Check Batteries / charge
batteries, Replace if
needed.
13
No ON / Supply power to the
control system
Over load
Mechanical fault
Faulted controller
Faulty power unit
Short circuit occur
Try to reset 2 times.
Troubleshoot the fault.
Replace the controller.
Replace the power unit.
Find and repair short circuit.
Note: Main Fuse is located
under the seat.
