5. Mechanical Adjustments
#
Description
Where
How to Adjust
1
Seat Height
Seat pin under the battery
cover.
See attached assembling
drawing:
Release both secure bolt and
level bolt. Change pin Level
hole as required . Rescuer
both level bolt and secure bolt.
Adjustments : 3 x 20 mm.
