Afikim Breeze-C Maintenance Manual


2. Specific Tools for technicians
 Standard tool box (wrenches, socket-head cap screw, hexagon keys, Phillips
(crosshead) tip and/or screwdrivers, etc.)
 Voltmeter (To measure 24VDC)
 Air pressure gauge (To measure 35 psi)
 Batteries tester (under load)
 Density meter
 Valve Wrench
 Wooden blocks to elevate the Breeze during checks, maintenance and repairs:
 2 blocks 20-22 centimeters height to place beneath the batteries box.
 2 blocks 14-16 centimeters height to place beneath the foot rest area.
 Remark : Always before operating a lifted Breeze make sure that the 2
rear wheels are free to turn , so that the scooters will not move.
3. Specific Parts:
We recommend the availability of the following set of test and repair assemblies:
1. Front Board
2. Main Harnesses Cable.
3. Main Lights Harness Cable.
4. Main Supply Harnesses.
5. Controller S-Drive 120A - P&G
6. Motor/Power Unit
7. Also it is very much recommended hold and use P&G SP1 Programmer (for S-
Drive, possible to upgrade old model of SP1 programmer to fit the S-Drive free
of charge.
