10.3 The fault code from the SP1 Programmer :
(More codes you can see on the hand programming SP1).
When the fault exists, connect the SP1 programmer's connector directly to the controller
SDRIVE or to the charging socket, using a special wiring adaptor.
The fault will be displaed on the SP1 programmer display.
Table 1:
Fault Code
Action to troubleshoot
0300
Check the tiller & throttle wiring to the controller, then retest
0815
Check the tiller & throttle wiring to the controller, then retest
0A00
Check the sleep mode parameter is set correctly, then retest
0E08
Check the tiller & throttle wiring to the controller, then retest
0E07
Check the tiller & throttle wiring to the controller, then retest
1501
Check the solenoid brake’s wiring & connections to the controller, then retest
1502
Check the solenoid brake’s wiring & connections to the controller, then retest
1600
Check the batteries’ wiring & connections to the controller, then retest
Also possible a condition of high load driving downhill.
1601
Check the batteries’ wiring & connections to the controller, then retest
1E08
Check the wiring & connections to pin 4 of the programming socket, then retest
1E09
Check the wiring & connections to pin 6 of the 14 way tiller connector, then retest
Inhibit 2 - check EMB manual brake micro switch.
1E0A
N/A for Breeze C.
2C00
Check the batteries’ wiring & connections to the controller, then retest
2F01
Check the throttle is not displaced on start-up, or does not return to natural condition ,
then retest
2F01
Check the tiller & throttle wiring to the controller, then retest
3100
Battery connected whilst scooter is switched on. Turn off, wait 10 seconds, then retest
3B01
Check the motor wiring & the connections to the controller, then retest
3D02
Check the motor wiring & the connections to the controller, then retest
3D03
Check the motor wiring & the connections to the controller, then retest
4401
Internal controller fault. Replace the controller (Make sure for the parameters setup).
5300
Programmable parameter changed. Turn the scooter off, then ON again, then retest
All the others
Check all wiring & connections to the controller, then retest
Table 2:
No power to programmer
Check the wiring & connections to the batteries, then retest
No power to programmer
Check the wiring & connections to the programmer, then retest
Scooter drives slowly
Check the controller is programmed correctly, then retest
Scooter drives slowly
Check the speed limiting function is not active e.g. seat raised, then retest
Scooter drives slowly
Check the solenoid brakes are not jammed, then retest
Status indicator does not light
Check the wiring & connections to the status indicator, then retest
Reverse alarm does not sound
Check the wiring & connections to the buzzer then retest
Reverse alarm does not sound
Check the buzzer is working correctly, then retest
Reverse alarm does not sound
Check the scooter is programmed correctly then retest
Scooter will not drive in reverse
Check the tiller wiring & connections, then retest
Scooter will not drive in reverse
Check the reverse switch is working correctly, then retest
