Remove batteries terminal insulating cap. Each time remove only one cap.
Unsecure the screw of the wiring terminal from battery terminal using 8 mm
key. Make sure your 8 mm key is not touching any other terminal or metal
part. This can cause damage and Injure.
After un securing all wires terminals, remove the batteries and install the new
ones. Connect the wires as shown in below Figure 11. The connection Label
is also located near the batteries.
Secure all wires to the frame with Ties as shown in Figure 11.
Secure all terminals with screws and make sure insulating caps are correctly
placed on terminals.
Warning! Batteries contain high energy. Misconnection, short circuits can
burst with strong sparks causing heat and possible fire.
Warning! Working with batteries can cause damage and Injure if not done
properly.
Note! Replacing batteries should be done only by trained and or professional
person.
