CHAPTER 5 – OPERATING INSTRUCTIONS
(Numbers in the table refers to figure no.6 and figure no.7)
Breeze C has a Main Key Switch (1.17) - located at the top of
the Tiller Box (1).
The Main Key Switch has two positions:
“OFF” - The Breeze C cannot be driven and the Electromagnetic
Brake is locked.
“ON” - Power is supplied to the Breeze C. The Electromagnetic
Brake releases automatically when the Operating Wig-Wag lever is
squeezed. To operate the Breeze C, insert the key into the Main Key
Switch and turn it to “ON” (clockwise). The switch will remain in this
position and the green LED (5.2) will be lit.
Note : Key Switch is used for operating the Breeze C , but not for
locking .
Automatic
Shut Off
(optional)
When Key Switch is at “ON” position, after a few minutes (usually 20
minutes) without using the Operating Lever, the control system will be
shut off automatically to save battery energy. This is an optional
feature. In such cases, to restart control system, turn Main Key Switch
“OFF” and “ON” again.
The Battery Capacity Indicator (5.1) located on top of the Tiller Box
shows you the remaining capacity of the batteries. Like in cars the
Batteries indicator is not absolute accurate, but will help you from
running out of fuel. The best way to use the battery indicator is to learn
it's behavior to the change of the battery capacity. When the indicator
points to the yellow area, recharge batteries as soon as possible.
When the indicator points to the red area you should get to immediate
charging, it is possible to drive only a short distance (1-4 km on level
surface).The accuracy of the battery indicator reading depends also on
the type and age of the batteries.
The Breeze C ON LED indicator (5.2) is also uses as a Fault
indication. When the LED is flashing, It blinks in a code of the fault.
(See Maintenance Manual for code definition).
Adjusting the
Hand Brake
(1.12)
(optional)
The hand brake cable mechanism can be adjusted by an authorized
serviceman, dealer or by any professional authorized to adjust hand
brakes mounted on bicycles or motorcycles.
The Hand Brake is part of your safety system.
DO NOT adjust the Hand Brake by yourself-get professional
assistance! The hand Brake is optional.
Speed Limit
Potentiometer
The Speed Limit Potentiometer (1.11) is located on the handlebar
panel. Turn maximum clockwise to the max. sign to drive at maximum
speed or turn maximum counter clockwise to the min. sign to drive at
minimum speed:
At max. sign the Breeze C will drive at 10 or 12 km/hr depand on the
model.
At min sign the Breeze C will drive at minimal speed of about 3
km/hr.
Do not shift the Speed Limit Potentiometer while the Breeze C is in
motion.
Notes:
1. When driving the Breeze inside a building or in a crowded
area, use lower speed mode.
2. When you just get the new Breeze C until you get used to it,
drive only in lower speed mode.
